KRS02
Steer Axle us
Ideal for high horsepower vehicles including EVs
A premium regional steer tire, the KRS02(e) features Tread Centering Groove Technology (TCG) for improved performance and tread wear uniformity. This outstanding all-position use tire was designed and engineered to meet the demanding requirements of regional and pickup and delivery applications.
Tire Highlights
- Uniform tread wear
- Fuel efficiency
Features & Benefits
- Outstanding general purpose performance and all-position capable, featuring a non-decoupling groove and five-rib design.
- Engineered and constructed for a long, original tread life with an improved 20/32 tread design.
- Kumho SmartWay verified tires use special, low rolling resistance tread cap & base compounds to improve wear and fuel economy.
The Kumho Tire Warranty Program
NOTE:NOT VALID FOR OE TIRES
KUMHO MANUFACTURER'S WARRANTY+-
All Kumho commercial tires are covered for a minimum of 60 months from the date of purchase. Long haul Smartway verified tires have coverage for 72 months.
Size & Technical Data
16 Inch (1 sizes)
7.50R16
| Product Code | Tire Size | Max Load (lbs) @ Cold Inflation Pressure (psi) Dua | Max Load (lbs) @ Cold Inflation Pressure (psi) Single | Measuring Rim Width | Approved Rim Width | Overall Dia (in.) | Ply Rating / Load Range | RPM | Section Width (in.) | Smartway | Tire Weight (lb) | Tread Depth (1/32") |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2278673 | 7.50R16 | 3195 @ 105 | 3305 @ 105 | 6.0 | 5.5 | 31.7 | 14 (G) | 659 | 8.1 | - | 57.3 | 14.0 |
22.5 Inch (1 sizes)
12R22.5
| Product Code | Tire Size | Max Load (lbs) @ Cold Inflation Pressure (psi) Dua | Max Load (lbs) @ Cold Inflation Pressure (psi) Single | Measuring Rim Width | Approved Rim Width | Overall Dia (in.) | Ply Rating / Load Range | RPM | Section Width (in.) | Smartway | Tire Weight (lb) | Tread Depth (1/32") |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2173423 | 12R22.5 | 6780 @ 120 | 7390 @ 120 | 9.0 | 8.2 | 42.7 | 16 (H) | 486 | 11.5 | - | 134.5 | 20.2 |
24.5 Inch (1 sizes)
285/75 R24.5
| Product Code | Tire Size | Max Load (lbs) @ Cold Inflation Pressure (psi) Dua | Max Load (lbs) @ Cold Inflation Pressure (psi) Single | Measuring Rim Width | Approved Rim Width | Overall Dia (in.) | Ply Rating / Load Range | RPM | Section Width (in.) | Smartway | Tire Weight (lb) | Tread Depth (1/32") |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1662513 | 285/75 R24.5 | 5675 @ 110 | 6175 @ 110 | 8.2 | 7.5 | 41.6 | 14 (G) | 500 | 10.6 | - | 120.4 | 19.5 |
